EMERSON ROSEMOUNT 5301HA1S1V3BE00403AAE5M1Q4Q8T1 GUIDED WAVE RADAR TRANS ID62505

EMERSON ROSEMOUNT 5301HA1S1V3BE00403AAE5M1Q4Q8T1 GUIDED WAVE RADAR TRANS ID62505

Part Numbers and Other Information: 5301HA1S1V3BE00403AAE5M1Q4Q8T1
Guided Wave Radar

5301HA1S1V3BE00403AAE5M1Q4Q8T1
5300 Guided Wave Radar
1 Transmitter Type: Liquid Level Transmitter (Interface available for fully submerged probe)
H Signal Output: 4-20 mA with HART communication
A Housing Material: Polyurethane-covered Aluminum
1 Conduit / Cable Threads: 1/2 - 14 NPT
S Operating Temperature and Pressure: - 15 psig (-1bar) to 754 psig (52 bar) at302 deg F (150 deg C)
1 Material of Construction; Process Connection/ Probe: 316/316L/EN 1.4404
V Sealing O-ring Material: FKM
3B Probe Type | Probe Length Limits: Coaxial,perforated. For lvl and interface meas, or easier cleaning Min:1'4"(0.4m); Max:19'8"(6m)
E Probe Length Units: English (feet, inches)
004 Probe Length (feet / meters): "feet" if English Units, "meters" if Metric Units. Min value is 1. (ie. 1-164 ft, 1-50 m)
03 Probe Length (inches / cm): "inches" if English Units, "cm" if Metric Units. Minvalue is 1. (ie. 1-11 in , 1-99 cm)
AA Process Connection Size / Type: 2 in. ANSI, 150 lb
E5 Hazardous Locations Certifications: USA Explosion-proof
M1 Display Type: Integral digital display
T1 Transient Terminal Block: Transient Protection Terminal Block
