EMERSON ROSEMOUNT 5301FA1S7E4AE00300AAE6M1P1Q4Q8 GUIDED WAVE RADAR TRANS ID07266

EMERSON ROSEMOUNT 5301FA1S7E4AE00300AAE6M1P1Q4Q8 GUIDED WAVE RADAR TRANS ID07266

Part Numbers and Other Information: 5301FA1S7E4AE00300AAE6M1P1Q4Q8
Guided Wave Radar

5301HA1S1V3BE00403AAE5M1Q4Q8T1
5300 Guided Wave Radar
1 Transmitter Type: Liquid Level Transmitter (Interface available for fully submerged probe)
H Signal Output: 4-20 mA with HART communication
A Housing Material: Polyurethane-covered Aluminum
1 Conduit / Cable Threads: 1/2 - 14 NPT
S Operating Temperature and Pressure: - 15 psig (-1bar) to 754 psig (52 bar) at302 deg F (150 deg C)
1 Material of Construction; Process Connection/ Probe: 316/316L/EN 1.4404
V Sealing O-ring Material: FKM
3B Probe Type | Probe Length Limits: Coaxial,perforated. For lvl and interface meas, or easier cleaning Min:1'4"(0.4m); Max:19'8"(6m)
E Probe Length Units: English (feet, inches)
004 Probe Length (feet / meters): "feet" if English Units, "meters" if Metric Units. Min value is 1. (ie. 1-164 ft, 1-50 m)
03 Probe Length (inches / cm): "inches" if English Units, "cm" if Metric Units. Minvalue is 1. (ie. 1-11 in , 1-99 cm)
AA Process Connection Size / Type: 2 in. ANSI, 150 lb
E5 Hazardous Locations Certifications: USA Explosion-proof
M1 Display Type: Integral digital display
T1 Transient Terminal Block: Transient Protection Terminal Block


Guided Wave Radar Head


Note ControlSetpoint only trades with the highest quality OEM items. We test each of our items and make sure they are not counterfeit and that they work as per the original specifications. We are very strongly against counterfeiters and if we find anyone trying to trade counterfeit items we will report them to the proper authorities. Our items come with a long warranty and are new surplus OEM unless indicated in the description as refurbished or used.

No Tariffs Shipped Within the USA!

We, at ControlSetpoint, appreciate our valued customers, please visit our store for additional items.

If you encounter any problems with the payment portal, please contact us immediately.

If you need more items than the quantity shown or need a variation of the item shown, please contact us and we can manufacture, assemble or obtain more of the items you need.

If you need calibration to a desired range or affix a tagname to the instrument, please let us know. We can also customize your instrument. We can add a mounting bracket, install a desired manifold, single or double acting relays on positioners, seals, capillaries to any desired length and/or internal fill fluid to any specification and materials. For temperature instruments we can add a thermowell, thermocouple and/or RTD of any specification. Simply let us know what you need and we can help you!

Also we repair transmitters and other instruments. Let us know what you need repaired and we can give you a free evaluation!

If you have an inquiry about obsolete or hard to find items, please contact us, we, at ControlSetpoint, may be able to help you.

Note that ControlSetpoint offers worldwide shipping and next day delivery within the US. If you need next day delivery, please contact us right after your purchase to calculate shipping cost. ControlSetpoint offers next day delivery, if purchase is done before 1 pm, if not the item will go out the following day.

ControlSetpoint ships worldwide to all places allowable by law. If you have any problems with our checkout, please contact us.

Thank you for considering ControlSetpoint's products, we want to be part of your team for the long term. Note that we offer a 2-YEAR WARRANTY on items working under normal conditions! With us you have peace of mind. Please beware of companies or individuals who do not give you a warranty!
